100MHz bandwidths digital storage oscilloscope
Vino3001 Features:
100MHz bandwidths
1GSa/s Real Time sample rate
Large (7.0-inch) color display,WVGA(800×480)
Record length up to 40K
Trigger mode: edge/pulse width/line selectable video/slop/overtime etc.
USB host and device connectivity, standard
Multiple automatic measurements
Four math functions, including FFTs standard
Provides software for PC real-time analysis
Operationg Instructions:
The connection method between the main test line and the host
Trun on the power switch and enter into the main menu interface
RST in the red labled area is the reset key, if the screen keys are not working, please use a pin to insert the hole next to the RST and reset it.
Oscilloscope Detection
the following accessories are required for the function of oscilloscope:
1. oscilloscope probe
our machine are dual channel oscillo-scope. we provide two oscilloscope probles. we also add one probe as spare, choose one or two depending on your actual needs.
Dual-purpose probe:
hook type probe
pin type brobe
Earthingline 1pcs
Package List:
1 Set Main engine
1 pcs Charger
1 pcs The main test Line
1 Set The engine plug connect sensor and wire harness: the quantity is subjest to the parking list
1 Couple Cigar lighter plug(socked and plug)
3 pcs Oscilloscope Probe:2pcs+1pcs as spare
1 pcs Earthing line
1 pcs Nox Sensore adapter substitute
