Handheld Borescope Mini Engine Inspection Industrial Endoscope
This product is a handheld endoscope device. Through the image and video functions of the endoscope, non-destructive inspection of small parts and places where the human eye cannot directly observe; it is widely used in aviation, automobiles, pipelines, machinery and equipment, Testing areas in the chemical and other industries
Borescope Endoscope Parameters
Screen size: 2.7-inch fixed screen
Snake tube length: 1 meter rigid coil
LED: 6 LED lights
Pixels: 300,000 pixels
View angle: 60 degrees
Focus distance: 30 ~ 80mm
Working temperature range: -20℃ ~ 60℃
Battery: 4 * AA alkaline batteries
Waterproof grade: IP67
Display resolution: 960 * 240
Effective pixels: 720 * 625
No temperature control protection
Toolkit and carton packaging
Snake tube
| Camera dia. | Effective pixel | Focus distance | View angle | Tube length | LED |
| Φ3.9 | 320*240 | 10mm-30mm | 90˚ | 1m standard (Max. 20m) | 2X0402 LED |
| Φ5.5 | 640*480 | 30mm-80mm | 60 ˚ | 1m standard (Max. 20m) | 6X0402 LED |
| Φ5.5 | 720*480 | 30mm-80mm | 60 ˚ | 1m standard (Max. 20m) | 6X0603 LED |
